Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: COOLCAM
  • Model Number: NIP-31OGP
  • Type: Digital Camera
  • Style: Dome Camera
  • Sensor: CMOS
  • Technology: Pan / Tilt / Zoom
  • Special Features: ip camera
  • Server: P2P
  • Image Compression: MJPEG
  • Mobilephone monitor: Support Iphone/Ipad/3G phone/smartphone
  • Infrared Light: 22 IR LEDs, Night visibility up to 20 Mete
  • Supported OS: Microsoft Windows XP/Vista/Windows7
  • Browser: IE 6.0, IE7.0 IE8.0 firefox2.0 firefox3.0 .Google
  • Image Frame Rate: 15 FPS(VGA),30FPS(QVGA)
  • Image Sensor: 1/5" Color CMOS Sensor
  • Certification: CE,FCC,RoHS
  • Focal-Length: f:3.6mm,f:2.4

Packaging & Delivery

Packaging Details: Package Included 1 x IP Camera 1 x Power Adaptor 1 x Ethernet Cable 1 x Wi-Fi Antenna 1 x CD 1 x Bracket
Delivery Detail: in 3 weeks,it depends on your quantity



Product Description

              10X optical zoom P2P Outdoor IP66 waterproof ip camera with 22 LED lights

Item

         IP CAM  NIP-39 (10X zoom)

Image Sensor

Mage sensor

 1/2.9" Color CMOS Sensor



Display

1280x720



lens

         f:1.8-3.0,F:4.9mm(wide end)-49.0mm(remote end)



Mini.illumination

ICR open 0.5 Lux,ICR close 1Lux

Lens

Lens Type

10X Zoom



Viewing Angle

70 Degree

Domain name

Server

P2P

Video

Image Compression

H264



Image Frame Rate

30fps(max.)



Resolution

1280x720, 640 x 480(VGA), 320 x 240(QVGA)



 Flip Mirror Images

 vertical / Horizontal



mode

50Hz, 60Hz



Video parameter

 brightness, contrast ,saturation level

Communication

Ethernet

RJ-45 Interface 10/100Mbps



Supported Protocol

HTTP/DHCP/IP/TCP/UDP/FTP/SMTP/DDNS/PPPoE/UPnP/Onvif/VISCA



Mobile phone monitor

Support I phone/I pad/3G/4G/ phone/smart phone



Wireless Standard

  IEEE 802.11b/g/n



Wireless Standard

802.11b:11Mbps(max.)  802.11g:54Mbps(max.)  802.11n:300Mbps(max)



Wireless Security

 64/128-bit  WEP Encryption

 Physical

PTZ(Pan/Tilt)

 Horizontally:330°   Vertically: 90°



Infrared Light

6 IR LED,Night visibility up to 15 Meters



Product size

120(L) x120(W) x130mm(H)



Gross Weight

1.39kg/pc(Color box packing size:196x165x123mm)

Power

Specification

DC 5V/2A



Power Consumption

Watts(max)

Environment

Operate Temper

~ 55°C  (32°F~131°F)



Operating Humidity

 20% ~ 85% no-condensing



Storage Temper

 -10°C ~ 60°C (14°F ~140°F)



Storage Humidity

 0% ~ 90% no-condensing

PC requirements

CPU

 2.0GHZ or above (suggested 3.0GHz)



Memory Size

 512MB or above (suggested 1.0GHz)



Display card

 64M or above



Supported OS

 Microsoft Windows XP/Vista/Windows7



Browser

 IE 6.0, IE7.0 IE8.0 firefox2.0 firefox3.0 .Google

Certification

CE, RoHS, FCC

Warranty

1 year limited warranty







Specification:

 ITEM

 IP CAM (NIP-31OGPW3A0Z0R1)

Image Sensor

 Mage sensor

 1/5" Color CMOS Sensor

 Display

 640 x 480 (300K Pixels)

 Focal-Length

f:3.6mm,f:2.4

 Mini.illumination

0.5 Lux

 Lens

  Lens Type

Glass Lens

 Viewing Angle

90 Degree

Audio

Microphone

no

Domain name

Server

2P server

 Video

Image Compression

 MJPEG

Image Frame Rate

15 FPS(VGA),30FPS(QVGA)

 Resolution

640 x 480(VGA), 320 x 240(QVGA)

Flip Mirror Images

rtical / Horizontal

mode

50Hz, 60Hz or Outdoor

Video Parameters

Brightness, Contrast

 Communication

 Ethernet

One 10/100Mbps RJ-45

Supported Protocol

HTTP/DHCP/IP/TCP/UDP/FTP/SMTP/DDNS/PPPoE/UPnP

Mobilephone monitor

Support Iphone/Ipad/3G phone/smartphone

 Wireless Standard

 IEEE 802.11b/g

 Wireless Standard

 802.11b:11Mbps(max.)  802.11g:54Mbps(max.)

 Wireless Security

  64/128-bitWEP Encryption

 Physical

  Pan/Tilt Angle

 Horizontal:360° & Vertical: 90°

 Infrared Light

22 IR LEDs, Night visibility up to 20 Mete

 Product size

205(L) x220(W) x120mm(H)

 GrossWeight

1800g/pcs  (packing size:196x165x123mm)

 NetWeight

1208.5g/pcs (only product)

 Power

 Specification

 DC 5V/2.0A

 Power Consumption

 5 Watts

 Environment

 Operate Temper

 0°~ 55°C  (14°F~122°F)

 Operating Humidity

 20% ~ 85% non-condensing

  Storage Temper

 -10°C ~ 60° (14°F ~140°F)

 Storage Humidity

 0% ~ 90% non-condensing

PC Requirements

 CPU

 2.0GHZ or above (suggested 3.0GHz)

 Memory Size

512MB or above (suggested 1.0GHz)

 Display card

 64M or above

 Supported OS

 Microsoft Windows XP/Vista/Windows7

 Browser

 IE 6.0, IE7.0 IE8.0 firefox2.0 firefox3.0 .Google

 Certification

 CE,FCC,RoHS

  Warranty

 Limited 1-year warranty









Packaging & Shipping





WIFI ANTENNA ( Wire  products is not need to match the antenna)





Supports and device together







CD

 (include Driver ,Search Tool, User Manual)








DC POWER SUPPLY

(US/EU Optional;

5V 2.5A 1.5 meter)











SCREW

(Every three)











PACKING SPECIFICATIONS




Q,TY: 5 PCS

 N.W.:  13.9  KG

G.W.:  14.9 KG

MEAS:89.50X28.50X28.00CM







NETWORK CABLE

(0.8 meter)
